SRS-1212
4.42

SRS-1212

$4.42

Meanwell 0.5W DC-DC Regulated Single Output Converter with 12V0~42mA0.5W100mVp-p50KHz min.

- +
Availability:In stock
SKU Meanwell SRS-1212
Brand Meanwell
Details

SRS-1212 Meanwell Power Supply 0.5W DC-DC Regulated Single Output Converter SRS-12 SRS-0512 SRS-2412 SRS-4812 YCICT

Meanwell SRS-1212 Specifications

ORDER NO. SRS-0512 SRS-1212 SRS-2412 SRS-4812
OUTPUT DC VOLTAGE 12V
CURRENT RANGE 0~42mA
EFFICIENCY (Typ.) 60.00%
SPECIFICATIONS
OUTPUT RATED POWER 0.5W
RIPPLE&NOISE (max.) 100mVp-p
LINE REGULATION ±1.0%
LOAD REGULATION ±1.0%
VOLTAGE ACCURACY ±2.0% (Typ.) ±3.0% (max.)
SWITCHING FREQUENCY 50KHz min.
INPUT VOLTAGE RANGE 4.5-5.5V 10.8-13.2V 21.6-26.4V 43.2~52.8V
NORMAL VOLTAGE 5V 12V 24V 48V
INPUT CURRENT Full load 175mA 72mA 36mA 19mA
INPUT CURRENT No load 37mA 15mA 9mA 5mA
FILTER Capacitor type
PROTECTION Fuse recommended
PROTECTION OVERLOAD 150~350% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
SHORT CIRCUIT All output equipped with short circuit
Protection type : Hiccup mode, recovers automatically after fault condition is removed
ENVIRONMENT WORKING TEMP. -25~+71 (Refer to "Derating Curve")
WORKING HUMIDITY 20% ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -25~+105, 10~95% RH
TEMP. COEFFICIENT ±0.03% / (0 ~ 50)
VIBRATION 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes
SAFETY&EMC SAFETY STANDARDS EAC TP TC 020/2011 approved
WITHSTAND VOLTAGE I/P-O/P:1.5KVDC
ISOLATION RESISTANCE I/P-O/P: 100M Ohms / 500VDC / 25/ 70% RH
ISOLATION CAPACITANCE 80pF max.
EMC EMISSION Compliance to BS EN/EN55032 Class B, FCC part 15 Class B, EAC TP TC 020
EMC IMMUNITY Compliance to BS EN/EN61000-4-2,3,4,5,6,8, light industry level, criteria A, EAC TP TC 020
OTHERS MTBF 600khrs min. MIL-HDBK-217F (25)
DIMENSION 22.6*9.9*8.9mm or 0.89"*0.39"*0.35" inch (L*W*H)
PACKING 3.1g ; 22pcs/per tube, 3080pcs/140 tube/per carton

Meanwell SRS-1212 Features

l  Internal SMD technology

l  Cooling by free air convection

l  Non-conductive plastic case

l  Approvals: FCC/EAC/CE/UKCA

l  Low cost/High reliability

l  Built-in EMI filter

l  Dual in line package

l  2 years warranty

l  100% burn-in test

l  1500VDC I/O isolation

SRS-1212 Meanwell Power Supply 0.5W DC-DC Single Output Converter SRS-12 SRS-0512 SRS-2412 SRS-4812 DIP package YCICT

Meanwell SRS-1212 Mechanical Diagram

SRS-1212 Meanwell Power Supply 0.5W DC-DC Single Output Converter SRS-12 SRS-0512 SRS-2412 SRS-4812 DIP DMS EMI YCICT
