SPD-20HP-480S
25.37

SPD-20HP-480S

$25.37

Meanwell 20kA High Performance Surge Protection Device with 347~480VAC 50/60Hz 510VAC 5A

- +
Availability:In stock
SKU Meanwell SPD-20HP-480S
Brand Meanwell
Details

Meanwell SPD-20HP-480S is a thermally protected Surge Protective Device with 347~480VAC 50/60Hz 510VAC 5A. It is specially designed to be used in outdoor and commercial LED lighting fixtures for transient overvoltage protection. Meanwhile, the unit is constructed with thermally protected varistor technology. Its built-in thermal disconnect function provides additional protection to prevent catastrophic failure and fire hazard even under the extreme circumstances of varistor end-of-life or sustaining over voltage conditions. Furthermore, SPD-20HP-480S offers coordinated surge protection with more LED drivers than other SPDs thanks to its exceptionally low Measured Limiting Voltage (MLV) and Voltage Protection Level (U,). This lower clamping voltage could also help to extend the life-time of the luminaire. What’s more, SPD-20HP-480S highlights a built-in LED indicator that notifies when replacement of the module is needed.Meanwell SPD-20HP-480S price and specs 20kA Surge Protection Device 347~480VAC 50/60Hz 510VAC 5A YCICT

Meanwell SPD-20HP-480S Encoding

SPD Series Name
20 Maximum discharge current
HP Hihg Performance
480S 277S: 120-277VAC
480S: 347-480VAC

Meanwell SPD-20HP-480S Specifications

Model SPD-20HP-480S
OPERATING VOLTAGE 347~480VAC 50/60Hz
MCOV/UC (MAX. CONTINUOUS OPERATING VOLTAGE) 510VAC
CONTINUOUS CURRENT (max.) 5A
MLV (MEASURED LIMITING VOLTAGE) L-N: 1400V
L-G: 1560V
N-G: 1570V
UP (VOLTAGE PROTECTION LEVEL) -----
I (NOMINAL DISCHARGE CURRENT) n Note 10kA, 8/20μs
IMAX (MAX. DISCHARGE CURRENT) 20kA, 8/20μs
OPERATING TEMPERATURE -40 ~ +75
SAFETY STANDARDS UL1449(Fourth Edition), EAC TP TC 004 approved
DIMENSION 71.6*67.7*32 (L*W*H)
PACKING 0.243Kg/Unit ; 1.73Kg/one box(6pcs); 9.3Kg/carton(including 5 boxes

Meanwell SPD-20HP-480S Features

l  Low MLV/U

l  Thermally protected

l  Double insulation cable wire

l  LED status indicator

l  Series connection style

l  20KV surge protection capability

l  UL1449 type 4 component assemblies

l  Line to Ground & Line to Line protected

l  20kA maximum discharge current (l max), 8/20us

l  IP66 design for indoor or outdoor installations

l  Suitable for LED driver surge protection with classⅠinsulation

Meanwell SPD-20HP-480S price and datasheet 20kA Surge Protection Device 347~480VAC 50/60Hz 510VAC 5A YCICT

Meanwell SPD-20HP-480S Applications

l  Outdoor and commercial LED Lighting

l  Roadway lighting

l  Traffic lighting

l  Digital signage

l  Wall wash lighting

l  Parking garage/lot lighting

l  Flood lighting

l  Tunnel lighting

l  Street lighting

Meanwell SPD-20HP-480S price and specs 20kA Surge Protection Device 347~480VAC 50/60Hz 510VAC 5A SPD-20HP YCICT

Meanwell SPD-20HP-480S Mechanical Diagram

Meanwell SPD-20HP-480S price and specs 20kA Surge Protection Device 347~480VAC 50/60Hz 510VAC 5A SPD-20HP series YCICT
