6W 1"x1" Package 8:1 Ultra-Wide Input DC-DC Regulated Converter with 7mA301mA9V0-667mA

- +
Availability:In stock
SKU Meanwell SI06W8-09
Brand Meanwell
Details

Meanwell SI06W8-09 is a 6W isolated and regulated DC-DC converter with 7mA301mA9V0-667mA. The model features module type and DIP 1"x1"package. Meanwhile, the main highlights are as following: international standard pins, high efficiency up to 86%, wide working temperaturerange -40~+90℃, 3KVDC I/P-O/P isolation voltage, compliance to BS EN/EN55032 radiated Class A without extra components, continuous-mode short circuit, overload, Input under voltage protectionetc. Furthermore, the models account input voltage 9~75V 8:1 ultra-wide input range, and various output voltage, 3.3V/5V/9V/12V/15V/24V for single output, and ±5V/±12V/±15V for dual outputs. In view of its longevity, high reliability, and excellent quality, Meanwell SI06W8-09 is suitable forall kinds of systems, such as industrial control, telecommunication field, distributed power architecture,and so on.

SI06W8-09 Meanwell Power Supply 6W DC-DC SI06W8 SI06W8-03 SI06W8-05 SI06W8-12 SI06W8-15 SI06W8-24 SI06W8 YCICT

Meanwell SI06W8-09 Encoding

S Series Name S: Single Output D: Dual Output
106 Rated Wattage
W8 8:1 Ultra wide input voltage (9-75Vdc)
09 Output Voltage ( 3.3/5/9/12/15/24Vdc, ±5/±12/±15Vdc)
R Blank: Non-Remote control ( Standard model)
R: Built-in Remote control (Optional Model)

Meanwell SI06W8-09 Specifications

ORDER NO. INPUT OUTPUT EFFICIENCY (TYP.) CAPACITOR LOAD (MAX)
INPUT VOLTAGE (RANGE) INPUT CURRENT OUTPUT VOLTAGE OUTPUT CURRENT
NO LOAD FULL LOAD
SI06W8-03 Normal 12V,24V,36V,48V,72V(9~75V) 5mA 268mA 3.3V 0-1500mA 80.0% 1800μF
SI06W8-05 5mA 309mA 5V 0-1200mA 81.0% 1000μF
SI06W8-09 7mA 301mA 9V 0-667mA 82.5% 680μF
SI06W8-12 7mA 300mA 12V 0-500mA 85.0% 470μF
SI06W8-15 8mA 294mA 15V 0~400mA 86.0% 220μF
SI06W8-24 8mA 294mA 24V 0~250mA 85.0% 220μF
INPUT VOLTAGE RANGE 9~75Vdc
SURGE VOLTAGE (100ms max.) 100Vdc
FILTER Capacitor network
PROTECTION (Typ.) Fuse recommended. 2A Slow-Blow Type
OUTPUT VOLTAGE ACCURACY ±2%
RATED POWER 6W
RIPPLE & NOISE 100mVp-p
LINE REGULATION ±0.2% (±0.5% for 3.3Vo)
LOAD REGULATION ±0.5%
SWITCHING FREQUENCY 300KHz (PWM)
PROTECTION SHORT CIRCUIT 110 ~ 230% rated output power
OVERLOAD 110 ~ 230% rated output power
Protection type : Recovers automatically after fault condition is removed
OVER VOLTAGE Protection type : Clamp by TVS diode
UNDER VOLTAGE LOCKOUT Start-up voltage: 8.8V
Shutdown voltage: 8.5V
FUNCTION REMOTE CONTROL (OPTIONAL) Power ON: RC ~ -Vin > 2.5Vdc ~ 6Vdc or open circuit
Power OFF: RC ~ -Vin <1Vdc or short
ENVIRONMENT COOLING Free-air convection
WORKING TEMP. -40 ~ +90 (Refer to "Derating Curve")
CASE TEMPERATURE +105 max
WORKING HUMIDITY 5% ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY -55 ~ +125, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT ±0.05% / (0 ~ 71)
SOLDERING TEMPERATURE 1.5mm from case of 1 ~ 3sec./260 max
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY&EMC SAFETY STANDARDS EAC TP TC 004 approved
WITHSTAND VOLTAGE I/P-O/P:3KVDC
ISOLATION RESISTANCE I/P-O/P:1000M Ohms / 500VDC / 25/ 70% RH
ISOLATION CAPACITANCE (Typ.) 1000pF
EMC EMISSION Parameter Standard Test Level
Conducted BS EN/EN55032(CISPR32) NA
Radiated BS EN/EN55032(CISPR32) Class A without external components
Class B with external components
EMC IMMUNITY Parameter Standard Test Level
ESD BS EN/EN61000-4-2 contact ±4KV
Radiated Susceptibility BS EN/EN61000-4-3 3V/m
EFT/Burest BS EN/EN61000-4-4 ±0.5KV
Surge BS EN/EN61000-4-5 Line-Line±0.5KV
Conducted BS EN/EN61000-4-6 3Vrms
Magnetic field immunity BS EN/EN61000-4-8 1A/m
OTHERS MTBF >400Khrs MIL-HDBK-217F(25)
DIMENSION 25.4*25.4*10.2mm (1*1*0.401 inch)
CASE MATERIAL Black coated copper with non-conductive base
PACKING 20g; 10pcs/per tube, 600pcs/60 tube/per carton

Meanwell SI06W8-09 Features

l  3KVDC I/O isolation

l  Remote ON/OFF control (optional)

l  3 years warranty

l  High efficiency up to 86%

l  8:1 ultrawide input range

l  Operating temperature range -40~+90℃

l  No minimum load required

l  DIP 1"x1" package with industry standard pinout

l  Comply to BS EN/EN55032 radiated Class A without additional components

l  Protections: Short circuit (Continuous)/Overload/Over voltage/Input under voltage

SI06W8-09 Meanwell Power Supply 6W DC-DC Converter SI06W8 SI06W8-03 SI06W8-05 SI06W8-12 SI06W8-15 SI06W8-24 SI06W8 YCICT

Meanwell SI06W8-09 Applications

l  Telecom/Datacom system

l  Wireless network

l  Industrial control facility

l  Instrument

l  Analyzer

l  Detector

l  Data switch

SI06W8-09 Meanwell Power Supply 6W DC-DC Converter SI06W8 SI06W8-03 SI06W8-05 SI06W8-12 SI06W8-15 SI06W8-24 DI06W8 YCICT

Meanwell SI06W8-09 Mechanical Diagram

SI06W8-09 Meanwell Power Supply 6W DIP DC-DC Converter SI06W8 SI06W8-03 SI06W8-05 SI06W8-12 SI06W8-15 SI06W8-24 YCICT
