DEPARTMENTS
RDDW08F-12
12.27

RDDW08F-12

$12.27

Meanwell 8W DIP Package Reliable Railway DC-DC Converter with 24V10mA392mA±12V±0~333mA

- +
Availability:In stock
SKU Meanwell RDDW08F-12
Brand Meanwell
Details

Meanwell RDDW08F-12 is 8W DC-DC reliable railway converter with 24V10mA392mA±12V±0~333mA. Meanwhile, the unit stands out with module type and DIP24 package. The main features are as following:  international standard pins, high efficiency up to 86%, wide working temperature range -40~+85℃, 1.5KVDC I/P-O/P isolation voltage, compliance with EN501 55 railway standard, continuous-mode short circuit protection, etc. Moreover, the models account for different input voltage 9~36V and 18~75V 4:1 wide input range, and various output voltage, 3.3V/5V/12V/15V for single output, and ±5V/±12V/±15V for dual outputs. In view of its long lifetime, high reliability, and excellent quality, Meanwell RDDW08F-12 is suitable for railway, trams, buses, and also can be used in the harsh environment with high vibration, high dust, extremely low or high temperature, etc.
RDDW08F-12 Meanwell Power Supply 8W DIP Railway DC-DC Converter RDDW08F RDDW08F-05 RDDW08F-15 RSDW08 RDDW08 YCICT

Meanwell RDDW08F-12 Encoding

RDDW Series Name S: Single Mode, D: Dual Mode
08 Rated Wattage
F Input Voltage ((F: 9-36Vdc, G: 18-75Vdc)
12 Output Voltage (3.3/5/12/15Vdc, ±5/±12/15Vdc)

Meanwell RDDW08F-12 Specifications

ORDER NO. INPUT OUTPUT EFFICIENCY (TYP.) CAPACITOR LOAD (MAX)
INPUT VOLTAGE (RANGE) INPUT CURRENT OUTPUT VOLTAGE OUTPUT CURRENT
NO LOAD FULL LOAD
RDDW08F-05 Normal 24V (9~36V) 10mA 406mA ±5V ±0~800mA 82% 800μF
RDDW08F-12 10mA 392mA ±12V ±0~333mA 85% 333μF
RDDW08F-15 15mA 390mA ±15V ±0~265mA 85% 265μF
INPUT VOLTAGE RANGE F: 9~36Vdc, G: 18~75Vdc
SURGE VOLTAGE (100ms max.) 24Vin models : 50Vdc, 48Vin models : 100Vdc
FILTER Pi type
PROTECTION (Typ.) Fuse recommended. 24Vin models: 3A delay time Type, 48Vin models: 1.5A delay time Type
INTERNAL POWER DISSIPATION 500mW
OUTPUT VOLTAGE ACCURACY ±1.5%
RATED POWER 8W
RIPPLE & NOISE 50mVp-p
LINE REGULATION ±0.5%
LOAD REGULATION Single output models:±0.5%, Dual output models:±1%
CROSS REGULATION ±5% at 25%~100% load
SWITCHING FREQUENCY 100KHz
PROTECTION SHORT CIRCUIT Protection type : Continuous, automatic recovery
OVERLOAD 120 ~ 180% rated output power
Protection type : Recovers automatically after fault condition is removed
OVER VOLTAGE Protection type : Clamp by diode
UNDER VOLTAGE LOCKOUT Start-up voltage 12Vin: 24Vin: 8.8Vdc, 48Vin: 17Vdc
Shutdown voltage 24Vin: 8Vdc, 48Vin: 16Vdc
5Vin: 4.4Vdc, 12Vin: 8.8Vdc, 24Vin: 17Vdc, 48Vin
FUNCTION REMOTE CONTROL Power ON: R.C. ~ -Vin >3.5~36Vdc or open circuit ; Power OFF: R.C. ~ -Vin <1.2Vdc or short
ENVIRONMENT COOLING Free-air convection
WORKING TEMP. -40 ~ +85 (Refer to "Derating Curve")
CASE TEMPERATURE +100 max.
WORKING HUMIDITY 20% ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -55 ~ +125, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT 0.03% / (0~71)
SOLDERING TEMPERATURE 1.5mm from case of 1 ~ 3sec./260max.
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes; Mounting: compliance to EN61373(Category 1- Class B)
SAFETY&EMC SAFETY STANDARDS EAC TP TC 020/2011(EAC TP TC 004 for 48Vin type only) approved
WITHSTAND VOLTAGE I/P-O/P:1.5KVDC
ISOLATION RESISTANCE I/P-O/P:100M Ohms / 500VDC / 25/ 70% RH
ISOLATION CAPACITANCE (Typ.) 1000pF
EMC EMISSION Parameter Standard Test Level
Conducted BS EN/EN55032 Class A/B with external components
Radiated BS EN/EN55032 NA
EMC IMMUNITY Parameter Standard Test Level
ESD BS EN/EN61000-4-2 Level 2,±8KV air,±4KV contact
Radiated Susceptibility BS EN/EN61000-4-3 Level 2, 3V/m
EFT/Burest BS EN/EN61000-4-4 Level 1, 0.5KV
Surge BS EN/EN61000-4-5 Level 1, 0.5KV Line-Line
Conducted BS EN/EN61000-4-6 Level 2, 3V(e.m.f.)
RAILWAY STANDARD EN50155 including EN61373 for shock & vibration, EN50121-3-2 for EMC
OTHERS MTBF Single: 1500Khrs, Dual: 1300Khrs MIL-HDBK-217F(25)
DIMENSION 31.8*20.3*10.2mm (1.25*0.8*0.4 inch)
CASE MATERIAL Black coated copper with non-conductive base
PACKING 18.4g ; 10pcs/per tube, 500pcs/50 tube/per carton

Meanwell RDDW08F-12 Features

l  DIP24 package with standard pinout

l  Compliance with EN50155 railway standard

l  Wide operating temperature range -40~+85℃

l  3 years warranty

l  4:1 wide input range

l  Full encapsulated

l  1.5KVDC I/O isolation

l  Remote ON/OFF control

l  No minimum load required

l  Protections: Short circuit (Continuous)/Overload/Over voltage/Input under voltage

RDDW08F-12 Meanwell Power Supply 8W 24V DIP Railway DC-DC Converter RDDW08F RDDW08F-05 RDDW08F-15 RSDW08 RDDW08 YCICT

Meanwell RDDW08F-12 Applications

l  Wireless network

l  Industrial control facility

l  Instrument

l  Analyzer

l  Bus, tram, metro or railway system

l  Telecom/Datacom system

l  Highly vibrating, heavily dusty, exteremely low or high temperature harsh environment

RDDW08F-12 Meanwell Power Supply 8W DIP Package DC-DC Converter RDDW08F RDDW08F-05 RDDW08F-15 RSDW08 RDDW08 YCICT

Meanwell RDDW08F-12 Mechanical Diagram

RDDW08F-12 Meanwell Power Supply 8W DIP DC-DC Converter RDDW08F RDDW08F-05 RDDW08F-15 RSDW08 RDDW08 low cost YCICT
