MS-150
9.01
Details
Meanwell MS-150 Series Model Specifications
| OUTPUT VOLTAGE CODE | MS-150A | MS-150B | MS-150C | MS-150D | MS-150E | MS-150F | MS-150G | MS-150H | MS-150I | MS-150J | MS-150K | |
| Output( MS-150) | DC VOLTAGE | 2V | 3.3V | 5V | 7.5V | 12V | 15V | 18V | 24V | 27V | 33V | 48V |
| RATED CURRENT | 25A | 25A | 25A | 18A | 13A | 10A | 8.5A | 6.5A | 5.8A | 4.7A | 3.2A | |
| CURRENT RANGE | 0-25A | 0-25A | 0-25A | 0-18A | 0-13A | 0-10A | 0-8.5A | 0-6.5A | 0-5.8A | 0-4.7A | 0-3.2A | |
| PEAK LOAD | 30A | 30A | 30A | 20.7A | 15A | 11.5A | 9.8A | 7.5A | 6.7A | 5.4A | 3.6A | |
| RATED POWER | 50W | 82.5W | 125W | 135W | 156W | 150W | 153W | 156W | 156.6W | 155.1W | 153.6W | |
| RIPPLE & NOISE (max.) | 50 mVp-p | 80 mVp-p | 80 mVp-p | 1000 mVp-p | 150 mVp-p | 150 mVp-p | 150 mVp-p | 150 mVp-p | 150 mVp-p | 250 mVp-p | 250 mVp-p | |
| VOLTAGE ADJ. RANGE | 1.6-2.6V | 2.6-4V | 4-6V | 6-9V | 9-13.2V | 13.2-16.8V | 16.8-20V | 20-26.4V | 25-31V | 30-40V | 40-53V | |
| VOLTAGE TOLERANCE | ±3.0% | ±2.0% | ±2.0% | ±2.0% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% | |
| LINE REGUL ATION | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.3% | ±0.3% | ±0.3% | ±0.2% | ±0.2% | ±0.2% | ±0.2% | |
| LOAD REGULATION | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| SETUP, RISE TIME | 1500ms, 50ms, 20ms at full load | |||||||||||
| PROTECTION | OVERLOAD | 121 ~ 150% rated output power | 116 ~ 150% rated output power | |||||||||
| Protection type : Constant current limiting, recovers automatically after fault condition is removed | ||||||||||||
| OVER VOLTAGE | 2.7-4V | 4.1-5V | 6.1-7.5V | 9.1-11.2V | 13.3-18V | 16.9-22V | 20.1-26V | 26.5-35V | 31.1-39V | 40.1-48V | 53.1-60V | |
| Protection type : Shut down o/p voltage, re-power on to recover | ||||||||||||
| OVER TEMPERATURE | Protection type : Shut down o/p voltage, re-power on to recover | |||||||||||
| FUNCTION | REMOTE INHIBIT CONTROL | RC+/RC-: 0 ~ 0.8V or OPEN, POWER ON RC+/RC-: 4 ~ 12V POWER OFF | ||||||||||
Meanwell MS-150 Series Features
l 3 years warranty
l Built in active PFC, PF>0.95
l Universal AC input/ full range
l Remote Control on every individual output module
l Remote Sense on every single output module (MS-75, 150,210,300,360)
l Remote margin/V-Program (MS-210/360)
l Built in parallel function (MS-2 10/300/360)
l Protections: Short circuit/Overload/Over voltage for all output modules
l Additional 12V/0.1A auxiliary output for remote control
l Cooling by built-in DC fan with fan alarm function
l Various output configuration is selectable
