Meanwell 3W DIP Package DC-DC Medical Grade Regulated Converter

- +
Availability:In stock
SKU Meanwell MDS03F
Brand Meanwell
Details

Meanwell MDS03F Series is a 3W isolated and regulated DC-DC converter. The product features module type, and medical grade with DIP 24 package. At the same time, the main highlights are as following: international standard pins, high efficiency reaching up to 81%, wide working temperature range -40~+90℃, 6KVDC or 4.2KVAC I/P-O/P high isolation voltage, compliance with IEC60601-1 medical standard, continuous-mode short circuit protection, etc. In addition, MDS03F & MDD03F models account for different input voltage 9~36V and 18~75V 4:1 wide input range, and various output voltage: 5V/12V/15V for single output, and ±5V/±12V/±15V for dual output. Considering its high reliability, excellent quality, and competitive price, Meanwell MDS03F Series is very suitable for medical systems requiring ultra-low leakage current.

Meanwell MDS03F price and specs 3w DIP dc-dc medical Converter MDS03F-05 MDS03F-12 MDS03F-15 MDS03 MDD03 YCICT

Meanwell MDS03F Series Encoding

MD(S) Series Name S: Single Output
D: Dual Output
03 Rated Wattage
F Input voltage (F: 9-36Vdc, G: 18-75Vdc)
12 Output Voltage (5/12/15Vdc, ±5V/±12V/±15Vdc)

Meanwell MDS03F Series Model Specifications

ORDER NO. INPUT OUTPUT EFFICIENCY (TYP.) CAPACITOR LOAD (MAX)
INPUT VOLTAGE (RANGE) INPUT CURRENT OUTPUT VOLTAGE OUTPUT CURRENT
NO LOAD FULL LOAD
MDS03F-05 Normal 12V, 24V (9 ~ 36V) 20mA 320mA 5V 0-600mA 80% 330μF
MDS03F-12 20mA 320mA 12V 0-250mA 80% 47μF
MDS03F-15 20mA 320mA 15V 0-200mA 80% 47μF
INPUT VOLTAGE RANGE F: 9~36Vdc , G: 18~75Vdc
SURGE VOLTAGE (100ms max.) F models : 50Vdc ; G models : 100Vdc
FILTER Pi type
PROTECTION (Typ.) Fuse recommended. F models: 2A slow-blow Type, G models: 1A slow-blow Type
OUTPUT VOLTAGE ACCURACY ±2.0%
RATED POWER 3W
RIPPLE & NOISE 150mVp-p
LINE REGULATION ±0.5%
LOAD REGULATION ±0.5%
SWITCHING FREQUENCY (Typ.) 250KHz
PROTECTION SHORT CIRCUIT Protection type : Continuous, automatic recovery
OVERLOAD 110~250% rated output power
Protection type: Recovers automatically after fault condition is removed
ENVIRONMENT COOLING Free-air convection
WORKING TEMP. -40 ~ +90 (Refer to "Derating Curve")
CASE TEMPERATURE +105 max
WORKING HUMIDITY 20% ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -55 ~ +125, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT 0.05% / (0 ~ 71)
SOLDERING TEMPERATURE 1.5mm from case of 3 ~ 5sec./265 max.
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY&EMC SAFETY STANDARDS IEC60601-1(LVD) 3rd edition, EAC TP TC 020/2011(EAC TP TC 004 for 48Vin type only) approved
WITHSTAND VOLTAGE I/P-O/P:6KVDC or 4.2KVAC
ISOLATION RESISTANCE I/P-O/P:1000M Ohms / 500VDC / 25/ 70% RH
ISOLATION LEVEL Primary-secondary: 2xMOPP when system input voltage is with 250VAC, 50/60Hz
ISOLATION CAPACITANCE (Typ.) 20pF
EMC EMISSION Parameter Standard Test Level
Conducted BS EN/EN55011 N/A
Radiated BS EN/EN55011 Class A without external components
EMC IMMUNITY Parameter Standard Test Level
ESD BS EN/EN61000-4-2 ±15KV air
Radiated Susceptibility BS EN/EN61000-4-3 10V/m
EFT/Burest BS EN/EN61000-4-4 ±2KV
Surge BS EN/EN61000-4-5 ±2KV Line-Line
Conducted BS EN/EN61000-4-6 10Vrms(e.m.f.)
Magnetic Field BS EN/EN61000-4-8 30A/m
OTHERS MTBF >454Khrs MIL-HDBK-217F(25)
DIMENSION 31.8*20.3*12.2mm (1.25*0.8*0.48 inch)
CASE MATERIAL UL94V-0 plastic case
PACKING 17g ; 15pcs/per tube, 750pcs/50 tube max./carton

Meanwell MDS03F Series Features

l  DIP 24 package with international standard pinout

l  4:1 wide input range

l  Low patient leakage current <5μA

l  Wide operating temperature range -40 ~+90℃

l  Medical safety approved (2xMOPP) according to lEC60601-1

l  Protections: Short circuit (Continuous) / Overload

l  6KVDC or 4.2KVAC high I/O isolation (Reinforced isolation)

l  3 years warranty

Meanwell MDS03F price and specs 3w DIP Package dc-dc medical grade Converter MDS03F-05 MDS03F-12 MDS03F-15 YCICT

Meanwell MDS03F Series Applications

l  Medical devices

l  Medical oxygen monitor

l  CT scanning

l  Medical carts

l  Oral care equipment

l  Industrial control system

Meanwell MDS03F price and specs 3w DIP Package dc-dc medical Converter MDS03F-05 MDS03F-12 MDS03F-15 MDS03 MDD03 YCICT

Meanwell MDS03F Series Mechanical Diagram

Meanwell MDS03F price and datasheet 3w DIP Package dc-dc medical Converter MDS03F-05 MDS03F-12 MDS03F-15 YCICT
