LPVL-150-24
13.88

LPVL-150-24

$13.88

Meanwell 150W Single Output Switching Power Supply with 24V6.3A0-6.3A151.2W200mVp-p±5.0%±1.0%±2.0%47~63Hz89.00%

- +
Availability:In stock
SKU Meanwell LPVL-150-24
Brand Meanwell
Details

Meanwell LPVL-150-24 is 150W single output power supply with 24V6.3A0-6.3A151.2W200mVp-p±5.0%±1.0%±2.0%47~63Hz89.00%. The item highlights constant voltage design and 93~132VAC input. As a classⅡpower unit,  LPVL-150-24 is housed with the UL 94V-0 rated flame retardant plastic enclosure. In addition, the efficiency reaches high up to 90%, and fully encapsulated design with IP67 level enhances heat dissipation, this allows the model to fit the use at dry, damp and wet locations. What’s more, the unit is supplied with various protections such as Short circuit, Overload, Over voltage and Over temperature. Thanks to its high efficiency, excellent quality, and competitive price, Meanwell LPVL-150-24 is ideally suitable for LED lighting and LED moving sign applications

Meanwell LPVL-150-24 price and specs LPVL-150-12 LPVL-150-24 low cost high reliability 90-132VAC input IP67 YCICT

Meanwell LPVL-150-24 Encoding

LPV Series Name
L Black: AC Input range 180-305 VAC
L: AC Input range 90-132 VAC
150 Output wattage
24 Output voltage

Meanwell LPVL-150-24 Specifications

Model LPVL-150-24
OUTPUT DC VOLTAGE 24V
RATED CURRENT 6.3A
CURRENT RANGE 0-6.3A
RATED POWER 151.2W
RIPPLE & NOISE (max.) 200mVp-p
VOLTAGE TOL ERANCE ±5.0%
LINE REGULATION ±1.0%
LOAD REGULATION ±2.0%
SETUP, RISE TIME LPV-150: 500ms, 50ms / 230VAC 500ms, 50ms / 277VAC; LPVL-150: 1500ms, 50ms / 115VAC
HOLD UP TIME (Typ.) LPV-150: 18ms/230VAC 20ms/277VAC at full load; LPVL-150: 10ms/115VAC at full load
Input VOLTAGE RANGE LPV-150: 180 ~ 305VAC 254 ~ 431VDC; LPVL-150: 90~132VAC
FREQUENCY RANGE 47 ~ 63Hz
EFFICIENCY (Typ.) 89.00%
AC CURRENT LPV-150: 1.7A/230VAC 1.5A/277VAC; LPVL-150: 3.0A/115VAC
INRUSH CURRENT(Typ.) Black Type COLD START 60A(twidth=900μs measured at 50% Ipeak) at 230VAC
L Type COLD START 75A(twidth=900μs measured at 50% Ipeak) at 115VAC
MAX. No. of PSUs on 16A CIRCUIT BREAKER Black Type 2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC
L Type 1 units (circuit breaker of type B) / 2 units (circuit breaker of type C) at 115VAC
LEAKAGE CURRENT LPV-150: 0.25mA / 240VAC LPVL-150:0.25mA / 120VAC
PROTECTION OVERLOAD 110 ~ 150% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE 27-35V
Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE Shut down o/p voltage, recovers automatically after temperature goes down
ENVIRONMENT WORKING TEMP. -25 ~ +65 (Refer to "Derating Curve")
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +80, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/ (0 ~ 40 for LPV-150-12,15 and LPVL-150-12,24;0~50 for LPV-150-24,36,48)
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY & EMC SAFETY STANDARDS Black Type UL8750,CSA C22.2 No 250.13-12,UL879,CSA C22.2 No.207-M89,BIS IS15885(for LPV-150-12,24 only),EAC TP TC 004, IP67, IEC62368-1, BS EN/EN62368-1 approved
L Type UL8750(type”HL”),CSA C22.2 No 250.13-12,UL879,CSA C22.2 No.207-M89,IP67 approved
WITHSTAND VOLTAGE I/P-O/P:3KVAC
ISOLATION RESISTANCE I/P-O/P:>100M Ohms / 500VDC / 25/ 70% RH
EMC EMISSION Black Type Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2 Class A(<=80% load), BS EN/EN61000-3-3, EAC TP TC 020
L Type Compliance to FCC part 15
EMC IMMUNITY Black Type Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level, EAC TP TC 020
L Type Design refer to IEC61000-4-2,3,4,5,6,8,11; light industry level
Others MTBF 3361.2K hrs min. Telcordia SR-332 (Bellcore) ; 391.9Khrs min. MIL-HDBK-217F (25)
DIMENSION 191*63*37.5mm (L*W*H)
PACKING LPV-150: 0.74Kg;20pcs/15.8Kg/0.95CUFT; LPVL-150: 0.85Kg;20pcs/17Kg/0.95CUFT

Meanwell LPVL-150-24 Features

l  Constant voltage design

l  2 years warranty

l  90~132VAC input forLPVL-150

l  180~305VAC input for LPV-150

l  Fully encapsulated with IP67 level

l  ClassⅡpower unit, no FG

l  Fully isolated plastic case

l  Fanless design, cooling by free air convection

l  100% full load burn-in test

l  Low cost, high reliability

l  Listed in UL Sign Component Manual (SAM)

l  Protections: Short circuit/Overload/Over voltage/Over temperature

l  Type "HL" for use in class l, Division 2 hazardous (Classified) location luminaires for LPVL-150

Meanwell LPVL-150-24 price and specs 150w LPVL-150-12 LPVL-150-24 low cost high reliability 90-132VAC input YCICT

Meanwell LPVL-150-24 Mechanical Diagram

Meanwell LPVL-150-24 price and specs 150w LPVL-150-12 LPVL-150-24 low cost high reliability 90-132VAC input IP67 YCICT
