KAA-4R4V-10S
190.54

KAA-4R4V-10S

$190.54

Meanwell KNX LED actuator/dimmer

- +
Availability:In stock
SKU Meanwell KAA-4R4V-10S
Brand Meanwell
Details

Meanwell KAA-4R4V-10S is a 4 channels device with 21-31V<14mA<250mW. The product features high quality independent latching relay to turn on or off, which is suitable for Meanwell all kinds of LED drivers. The specifications indicate the maximum number of recommended LED drivers per channel, which is easy for building planning. Based on the KNX architecture, KNX system engineers can easily program through the ETS system as needed during planning or use, or manually through the physical buttons on the panel. Furthermore, KAA-4R4V-10S is independently configured with a green LED on each channel to indicate the status of the switch. The compact design with 4 units (72mm) wide modular makes it suitable for installation in the distribution board on 35mm mounting rails in the EIB/KNX application. The connection to the KNX bus is implemented via a bus connection terminal. Additionally, the new version supports KNX Data Secure function. KNX Data Secure offers protection against manipulation in building automation, and can be configured in the ETS project. Apart from the basic switch function, a DC O (1)-10V interface by current sinking is provided for dimming the connected LED driver or ballast. The dimming curve can be adjusted to linear or logarithmic mode, so that the end user has excellent dimming experience. Moreover, it can be used with motion sensors in the buildings to save energy. The dimmer is powered via the EIB/KNX and do not require any additional power supply. As result, KAA-4R4V-10S is featuring both reliability and multi functionality to meet various needs in a modern building.

KAA-4R4V-10S price and specs KNX LED dimmer KAA-4R4V-S programable via ETS software Support KNX Data Secure YCICT

Meanwell KAA-4R4V-10S Encoding

KAA Series Name
4R4V R: Relay on/off for 4-channel (4 fold) V: 0(1)-10V dimming for 4-channel (4 fold)
-10: 10A per channel
Blank: 16A per channel
S Built-in with KNX Secure function
-10 4 Channel actuator, 10A per channel
Blank 4 Channel actuator, 16A per channel

Meanwell KAA-4R4V-10S Specifications

MODEL KAA-4R4V-10S
SUPPLY KNX BUS VOLTAGE 21-31V
CURRENT CONSU MPTION <14mA
POWER CONSUMPTION <250mW
OUTPUT CONTROL VOLTAGE RANGE 0-10V
NO. OF CONTROL OUTPUT 4
TYPE OF CONTROL passive
MAX. CABLE LENGTH AT FULL LOAD 50mA
MAX. CURRENT PER OUTPUT 100m with cable cross-section 1.5mm2
OUTPUT RELAY OUTPUT SWITCHING RATINGS Nr. OF RELAY 4
Nr. OF SHUTTER OUTPUT 2
INDEPENDENT & POTENTIAL-FREE PER RELAY Yes
CURRENT OHMIC LOAD 10A
CURRENT CAPACITIVE LOAD 220μF(See Note.2)
MAX. INRUSH CURRENT 400A(max. 200μs),80A(max. 20ms)
EN60947-4-1 AC1(COS Ѳ=0.8) 10A
EN60947-4-1 AC5a(COS Ѳ =0.45) 8A
EN60947-4-1 AC5b 10A
MAX. TOTAL CURRENT OF THE ACTUATOR 40A
OUTPUT SERVICE LIFE MECHANICAL SERVICE LIFE >106
ELECTRICAL ENDURANCE EN60669-1 19.1 4*104(See Note.2)
EN60669-1 19.2, FLOURSCENT LAMP(AX) 104(See Note.2)
OPERATING & DISPLAY PROGRAMMING BUTTON/LED For set the individual address
MANUAL BUTTON/LED For manually control the relay and dimming
ENVIRONMENT WORKING TEMP. -30 ~ +45 (3K5)
STORAGE TEMP. -35 ~ +70
WORKING HUMIDITY 10 ~ 95% RH non-condensing
PROTECTION CLASS , According to EN61140
OVER VOLTAGE CATEGORY ,According to EN60664-1
POLLUTION DEGREE 2, According to EN60664-1
DEGREE OF PROTECTION IP20,According to EN60529
SAFETY & EMC SAFETY STANDARDS BS EN/EN50491-3, BS EN/EN60669-1, BS EN/EN60669-2-1, BS EN/EN60669-2-5(See Note.2), EAC TP TC 004 approved
EMC EMISSION Compliance to BS EN/EN50491-5-1,-2,-3, BS EN/EN50090-2-2, BS EN/EN60669-2-1, BS EN/EN60669-2-5, BS EN/EN63044-5-1,-2,-3(See Note.2), EAC TP TC 020
EMC IMMUNITY Compliance to BS EN/EN50491-5-1,-2,-3, BS EN/EN50090-2-2, BS EN/EN60669-2-1, BS EN/EN60669-2-5, BS EN/EN63044-5-1,-2,-3(See Note.2), EAC TP TC 020
WITHSTAND VOLTAGE Between switching and SELV control circuit3.5KVAC
CONNECTIONS SCREW TERMINAL 0.5 – 4.0mm² solid core 0,5 - 2,5mm² finely stranded
  KNX BUS CONNECTION TERMINAL 0.8mmψ, solid core
OTHERS MTBF 686.9K hrs min. Telcordia SR-332 (Bellcore) ; 302.3K hrs min. MIL-HDBK-217F (25)
DIMENSION 72*90*57mm (W*H*D)
MOUNTING WIDTH IN UNITS 4
DIN RAIL MOUNTING 35mm mounting rail according to DIN EN60715
PACKING 0.247Kg ; 48pcs/12.53Kg/1.02CUFT

Meanwell KAA-4R4V-10S Features

l  3 years warranty

l  LED indicator for each channel

l  Linear or logarithmic dimming curve

l  programable via ETS software

l  Support KNX Data Secure

l  Manual control via Push button on panel

l  Programmable various time and scene function

l  Dimming and switching LED driver and conventional electronic ballast

KAA-4R4V-S price and specs KNX LED actuator/dimmer 21~31V programable via ETS software Support KNX Data Secure YCICT

Meanwell KAA-4R4V-10S Applications

l  Building Automation

l  Lighting switch/dimming control

l  Shutter/Blind control

KAA-4R4V-S price and datasheet KNX LED actuator/dimmer 21~31V programable via ETS software Support KNX Data Secure YCICT

Meanwell KAA-4R4V-10S Mechanical Diagram

KAA-4R4V-S price and specs KNX LED actuator KAA-4R4V-10S programable via ETS software Support KNX Data Secure YCICT
