Meanwell 6W 1"x1" Package 8:1 Ultra-Wide Input DC-DC Regulated Converter with 11mA300mA±15V±0~200mA

- +
Availability:In stock
SKU Meanwell DI06W8-15
Brand Meanwell
Details

Meanwell DI06W8-15 is a 6W isolated and regulated DC-DC converter with 11mA300mA±15V±0~200mA. At the same time, the unit features module type and DIP 1"x1"package. The main highlights are as following: international standard pins, high efficiency up to 86%, wide working temperaturerange -40~+90℃, 3KVDC I/P-O/P isolation voltage, compliance to BS EN/EN55032 radiated Class A without extra components, continuous-mode short circuit, overload, Input under voltage protectionetc. Apart from them, the models account input voltage 9~75V 8:1 ultrawide input range, and various output voltage, 3.3V/5V/9V/12V/15V/24V for single output, and ±5V/±12V/±15V for dual outputs. As a result of its longevity, high reliability, and excellent quality, Meanwell DI06W8-15 is suitable forall kinds of systems, such as industrial control, telecommunication field, distributed power architecture,and so on.

DI06W8-15 Meanwell Power Supply 6W DIP 1"x1" Package DC-DC Converter DI06W8 DI06W8-05 DI06W8-12 SI06W8 low cost YCICT

Meanwell DI06W8-15 Encoding

D Series Name S: Single Output D: Dual Output
106 Rated Wattage
W8 8:1 Ultra wide input voltage (9-75Vdc)
15 Output Voltage ( 3.3/5/9/12/15/24Vdc, ±5/±12/±15Vdc)
R Blank: Non-Remote control ( Standard model)
R: Built-in Remote control (Optional Model)

Meanwell DI06W8-15 Specifications

ORDER NO. INPUT OUTPUT EFFICIENCY (TYP.) CAPACITOR LOAD (MAX)
INPUT VOLTAGE (RANGE) INPUT CURRENT OUTPUT VOLTAGE OUTPUT CURRENT
NO LOAD FULL LOAD
DI06W8-05 Normal 12V,24V,36V,48V,72V(9~75V) 7mA 309mA ±5V ±0~600mA 81.0% 470μF
DI06W8-12 9mA 295mA ±12V ±0~250mA 85.0% 100μF
DI06W8-15 11mA 300mA ±15V ±0~200mA 84.5% 100μF
INPUT VOLTAGE RANGE 9~75Vdc
SURGE VOLTAGE (100ms max.) 100Vdc
FILTER Capacitor network
PROTECTION (Typ.) Fuse recommended. 2A Slow-Blow Type
OUTPUT VOLTAGE ACCURACY ±2%
RATED POWER 6W
RIPPLE & NOISE 100mVp-p
LINE REGULATION ±0.2% (±0.5% for 3.3Vo)
LOAD REGULATION ±0.5%
SWITCHING FREQUENCY 300KHz (PWM)
PROTECTION SHORT CIRCUIT 110 ~ 230% rated output power
OVERLOAD 110 ~ 230% rated output power
Protection type : Recovers automatically after fault condition is removed
OVER VOLTAGE Protection type : Clamp by TVS diode
UNDER VOLTAGE LOCKOUT Start-up voltage: 8.8V
Shutdown voltage: 8.5V
FUNCTION REMOTE CONTROL (OPTIONAL) Power ON: RC ~ -Vin > 2.5Vdc ~ 6Vdc or open circuit
Power OFF: RC ~ -Vin <1Vdc or short
ENVIRONMENT COOLING Free-air convection
WORKING TEMP. -40 ~ +90 (Refer to "Derating Curve")
CASE TEMPERATURE +105 max
WORKING HUMIDITY 5% ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY -55 ~ +125, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT ±0.05% / (0 ~ 71)
SOLDERING TEMPERATURE 1.5mm from case of 1 ~ 3sec./260 max
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY&EMC SAFETY STANDARDS EAC TP TC 004 approved
WITHSTAND VOLTAGE I/P-O/P:3KVDC
ISOLATION RESISTANCE I/P-O/P:1000M Ohms / 500VDC / 25/ 70% RH
ISOLATION CAPACITANCE (Typ.) 1000pF
EMC EMISSION Parameter Standard Test Level
Conducted BS EN/EN55032(CISPR32) NA
Radiated BS EN/EN55032(CISPR32) Class A without external components
Class B with external components
EMC IMMUNITY Parameter Standard Test Level
ESD BS EN/EN61000-4-2 contact ±4KV
Radiated Susceptibility BS EN/EN61000-4-3 3V/m
EFT/Burest BS EN/EN61000-4-4 ±0.5KV
Surge BS EN/EN61000-4-5 Line-Line±0.5KV
Conducted BS EN/EN61000-4-6 3Vrms
Magnetic field immunity BS EN/EN61000-4-8 1A/m
OTHERS MTBF >400Khrs MIL-HDBK-217F(25)
DIMENSION 25.4*25.4*10.2mm (1*1*0.401 inch)
CASE MATERIAL Black coated copper with non-conductive base
PACKING 20g; 10pcs/per tube, 600pcs/60 tube/per carton

Meanwell DI06W8-15 Features

l  DIP 1"x1" package with industry standard pinout

l  Comply to BS EN/EN55032 radiated Class A without additional components

l  Protections: Short circuit (Continuous)/Overload/Over voltage/Input under voltage

l  Operating temperature range -40~+90℃

l  Remote ON/OFF control (optional)

l  3 years warranty

l  3KVDC I/O isolation

l  High efficiency up to 86%

l  8:1 ultra-wide input range

l  No minimum load required
